MGFS302412 Real Image
Same model may have multiple batches, images only for reference.

MGFS302412

Part No MGFS302412
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V / Isolated Module DC DC Converter 1 Output 12V 2.5A 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr Cosel USA, Inc.
Series MGFS (30W)
Package Box
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Current - Output (Max) 2.5A
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP, OVP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 89%
Mounting Type Through Hole
Package / Case 6-DIP Module
Dimension 2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
Other Names 1776-1346
Standard Package 1
Win Source Part Number 1224833-MGFS302412
Ultra Librarian 3D Model Ultra Librarian MGFS302412 CAD Model

Description

The MGFS302412 is a 30W isolated module DC-DC converter from Cosel USA, Inc. Bold the product name (e.g., BAV99S,135 → MGFS302412) and manufacturer (e.g., Nexperia USA Inc. → Cosel USA, Inc.).

  • Power: 30W
  • Features: Remote On/Off, OCP, OVP
  • Standard Package: 1
  • Voltage Isolation: 1.5 kV
  • Output: Single
  • Maximum Output Current: 2.5A
  • Input Voltage: 9V to 36V
  • Output Voltage: 12V
  • Efficiency: 89%
  • Mounting Type: Through Hole
  • Package/Case: 6-DIP Module
  • Operating Temperature: -40°C to 85°C (with derating)
  • Dimensions: 2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
  • Application: ITE (Commercial)
