Same model may have multiple batches, images only for reference.

C2M0080120D

Name: C2M0080120D
Brand: Cree/Wolfspeed
SKU: 575721
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	C2M0080120D
Manufacturer	Cree/Wolfspeed
Catalog	Transistors - FETs, MOSFETs - RF
Description	SICFET N-CH 1200V 36A TO247-3
Datasheet	C2M0080120D Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Cree/Wolfspeed
Series	C2M™
Package	Bulk
Product Status	Not For New Designs
FET Type	N-Channel
Technology	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss)	1200 V
Current - Continuous Drain (Id) @ 25°C	36A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	20V
Rds On (Max) @ Id, Vgs	98mOhm @ 20A, 20V
Vgs(th) (Max) @ Id	4V @ 5mA
Gate Charge (Qg) (Max) @ Vgs	62 nC @ 5 V
Vgs (Max)	+25V, -10V
Input Capacitance (Ciss) (Max) @ Vds	950 pF @ 1000 V
Power Dissipation (Max)	192W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	TO-247-3
Package / Case	TO-247-3
Base Product Number	C2M0080120
Standard Package	30 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	575721-C2M0080120D
Ultra Librarian 3D Model	Ultra Librarian C2M0080120D CAD Model

Alternative Products

Description

The C2M™ SiCFET (Silicon Carbide) N-Channel FET by Cree/Wolfspeed is a high-performance electronic component designed for use in discrete semiconductor products.

Drain to Source Voltage (Vdss): 1200V
Continuous Drain Current (Id): 36A
On-Resistance (Rds On): 98mOhm
Gate Charge (Qg): 62nC
Mounting: Through-Hole
