The CreeLED, Inc. XPEBAM-L1-0000-00801 is a yellow LED with a viewing angle of 130° and a wavelength of 590nm (585nm ~ 595nm).

• Current - Test: 1A
• Thermal Resistance of Package: 7°C/W
• Standard Package: 1,000 units
• Packaging: Tape and reel
• Height: 0.094" (2.39mm)
• Dimension: 0.136" L x 0.136" W (3.45mm x 3.45mm)
• REACH Status: Compliant with REACH
• ECCN: EAR99
• Luminous Flux @ Current/Temperature: 77lm (74lm ~ 81lm) @ 350mA/25°C
• Lumens/Watt @ Current: 100 lm/W @ 350mA
• Alternative Parts: No alternative parts are available for this product.
