ATS098SM CTS Corporation
Same model may have multiple batches, images only for reference.

ATS098SM

Part No ATS098SM
Manufacturer CTS-Frequency Controls
Catalog Oscillators
Description 0009.830400 MHZ Crystal
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr CTS-Frequency Controls
Series ATS-SM
Package Bulk
Product Status Active
Type MHz Crystal
Frequency 9.3804 MHz
Frequency Stability ±50ppm
Frequency Tolerance ±30ppm
Load Capacitance 20pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Temperature Range - Operating -20°C ~ 70°C
Mounting Type Surface Mount
Package / Case HC-49/US
Size / Dimension 0.437" L x 0.190" W (11.10mm x 4.83mm)
Height - Seated (Max) 0.169" (4.30mm)
Base Product Number ATS-SM
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 566832-ATS098SM
Ultra Librarian 3D Model Ultra Librarian ATS098SM CAD Model

Description

The 566832-ATS098SM is a MHz crystal from the ATS-SM series.

  • Package: Bulk
  • Size: 0.437" L x 0.190" W (11.10mm x 4.83mm)
  • Height: 0.169" (4.30mm)
  • Frequency: 9.3804 MHz
  • ESR (Equivalent Series Resistance): 60 Ohms
  • Frequency Stability: ±50ppm
  • Frequency Tolerance: ±30ppm
  • Temperature Range: -20°C to 70°C
  • Mounting Type: Surface Mount
  • Package / Case: HC-49/US
