S25FL256SAGMFIG03 Real Image S25FL256SAGMFIG03 Real Image
Same model may have multiple batches, images only for reference.
S25FL256SAGMFIG03 Real Image S25FL256SAGMFIG03 Real Image
S25FL256SAGMFIG03 Real Image S25FL256SAGMFIG03 Real Image
Same model may have multiple batches, images only for reference.

S25FL256SAGMFIG03

Part No S25FL256SAGMFIG03
Manufacturer Cypress Semiconductor Corp
Catalog Flash
Description IC FLASH 256MBIT SPI/QUAD 16SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 12 Weeks
Features FLASH - NOR Memory IC 256Mb (32M x 8) SPI - Quad I/O 133 MHz 16-SOIC
Manufacturer Cypress Semiconductor Corp
Series FL-S
Package Reel - TR
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting Surface Mount
Package 16-SOIC (0.295", 7.50mm Width)
Case / Package 16-SOIC
Family Name S25FL256
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991B1A
HTSUS 8542.32.0071
Other Part Number 428-4644-1, 428-4644-2, 428-4644-6, S25FL256SAGMFIG03-ND
Quantity per package 1450
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 845367-S25FL256SAGMFIG03
Ultra Librarian 3D Model Ultra Librarian S25FL256SAGMFIG03 CAD Model

Description

The Cypress Semiconductor Corp S25FL256SAGMFIG03 is a high-performance flash memory chip by Cypress Semiconductor Corp.

  • Capacity: 256 megabits (Mb)
  • Speed: 133 megahertz (MHz)
  • Power Consumption: 8 milliwatts (mW)
  • Standby Current: 10 microamps (μA)
  • Series: FL-S
  • RoHS Compliant: Yes
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • Package: 16-SOIC
  • Estimated Production Lead Time: 12 weeks
