Product Overview: AP2511FGE-7

The AP2511FGE-7 is a high-performance, single channel current-limited integrated high-side power switch from Diodes Incorporated, designed for USB applications. Crafted with precision, this product is optimized for self-powered and bus-powered Universal Serial Bus (USB) and other hot-swap applications.

This power switch is equipped with a 2.7V to 5.5V input voltage range, making it versatile for various USB peripheral devices. The AP2511FGE-7 ensures protection for your USB devices by incorporating features such as over-current protection, under-voltage lockout, thermal shutdown, and reverse current protection. These features are crucial in safeguarding peripheral devices from electrical damage and ensuring reliable operation.

Key Features

• Current Limiting: The device provides a precise current limit to prevent excessive current from damaging the USB port and the connected device.
• Fast Short-Circuit Response: With a rapid response time to short circuits, the AP2511FGE-7 quickly reacts to protect the circuitry.
• Over-Temperature Protection: The built-in thermal shutdown function prevents overheating, enhancing the longevity of the product.
• Controlled Rise Time: Reduced inrush current is achieved with a controlled output rise time, minimizing current surges during device enablement.
• Under-Voltage Lockout (UVLO): The UVLO feature ensures the device operates at adequate power levels, protecting against voltage drops that could cause malfunction.

Applications

The AP2511FGE-7 is ideal for a wide range of applications where USB power distribution and protection are required. It is commonly used in:

• USB Hubs
• USB Peripheral Devices
• Hot-Swap Supplies
• Portable Consumer Electronics

With its compact form factor, the AP2511FGE-7 is available in a space-saving SOT-25 package, making it a perfect fit for portable devices where space is at a premium. Its commitment to safety and performance makes the AP2511FGE-7 an indispensable component for designers looking to create reliable and user-protective USB interfaces.

For additional information, technical specifications, and support resources, please refer to the datasheet and technical documentation provided by Diodes Incorporated for the AP2511FGE-7.
