The AP7313-33SAG-7 from Diodes Incorporated is a highly efficient, low dropout voltage regulator designed to deliver a fixed output voltage of 3.3V with an input voltage range from 3.5V to 24V. This regulator is an ideal choice for a wide range of applications, particularly where space is at a premium and extended battery life is a necessity.

Key Features:

• Fixed Output: This device provides a stable 3.3V output, making it suitable for consistent power supply needs.
• High Efficiency: With a low quiescent current of just 2.5µA, the AP7313-33SAG-7 ensures efficient use of power, contributing to the extended battery life of portable devices.
• Low Dropout: The low dropout voltage allows the regulator to continue to provide a regulated output even when the supply voltage is very close to the output voltage, which is beneficial during battery operation when the voltage may decline over time.
• Wide Input Voltage Range: Capable of handling input voltages from 3.5V to 24V, this regulator can be used with a variety of power sources.
• Thermal Shutdown: The built-in thermal shutdown feature protects the device from damage due to overheating.
• Current Limit Protection: With current limit protection, the AP7313-33SAG-7 prevents damage to the device and the circuit due to excessive current.
• Small Form Factor: The SOT-23 package is compact and suitable for space-constrained applications.

Applications:

The AP7313-33SAG-7 is versatile and can be used in various electronic devices, including:

• Battery-powered equipment
• Handheld devices
• Portable media players
• Microcontrollers and digital circuits
• Power management modules

Product Summary:

The AP7313-33SAG-7 voltage regulator by Diodes Incorporated is an excellent choice for designers looking for a reliable, consistent power solution that is both space and energy-efficient. With its comprehensive protection features and wide input voltage range, it is a robust component suitable for a broad array of electronic applications.
