The AZ431AZ-ATRE1 is a precision programmable shunt regulator from Diodes Incorporated, designed to maintain high stability and accuracy in a variety of applications. This three-terminal adjustable regulator features a guaranteed thermal stability over applicable temperature ranges, making it a versatile component for use in power supplies, battery chargers, and voltage monitoring systems.

Key Features

• Programmable Output Voltage: The AZ431AZ-ATRE1 offers an adjustable output voltage from 2.5V to 36V, providing flexibility for different circuit requirements.
• Low Dynamic Output Impedance: A low dynamic output impedance of 0.2 ohms ensures stable voltage regulation, which is critical for sensitive electronics.
• High Stability: With a guaranteed stability over a wide temperature range, this regulator is reliable in various operating conditions.
• Surface Mount Package: The device comes in a surface-mount package, making it suitable for automated assembly processes and compact circuit designs.

Applications

• Power supply systems
• Battery chargers
• Voltage monitoring circuits
• Adjustable power supplies
• Switching power supplies

Technical Specifications

The Diodes Incorporated AZ431AZ-ATRE1 is an ideal solution for designers looking for a reliable and flexible voltage reference. Its precision and programmability, combined with its high stability, make it a go-to component for a wide range of electronic applications.
