DMG2302UKQ-7 - MOSFET from Diodes Incorporated

The DMG2302UKQ-7 is a high-performance, P-channel enhancement mode MOSFET produced by Diodes Incorporated, a leading manufacturer and supplier of high-quality semiconductor products. This MOSFET is designed to deliver efficient power management and switching with low on-state resistance and a fast switching speed, making it an ideal choice for a wide range of applications.

Key Features

• Device Type: P-Channel MOSFET
• Configuration: Single
• Drain-Source Voltage (V<sub>DS): -20V
• Continuous Drain Current (I<sub>D): -4.3A
• R<sub>DS(on): 45 mOhms at V<sub>GS = -4.5V
• Power Dissipation (P<sub>D): 1.25W
• Operating Temperature Range: -55°C to +150°C
• Package: SOT-23

Applications

The DMG2302UKQ-7 is suitable for a variety of applications, including but not limited to:

• Power Management
• Load Switch
• Battery Protection
• DC-DC Converters
• Portable Devices

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products that meet rigorous industry standards. The DMG2302UKQ-7 is no exception, offering reliability and performance for critical applications. It is RoHS compliant and lead-free, ensuring environmental safety and catering to global regulatory requirements.

Summary

The DMG2302UKQ-7 from Diodes Incorporated is a robust P-channel MOSFET that offers low on-state resistance, fast switching capabilities, and efficient power management. Its compact SOT-23 package makes it suitable for space-constrained applications while providing the performance needed for demanding electronic systems. Whether for consumer electronics, industrial designs, or portable devices, the DMG2302UKQ-7 is a versatile component that engineers and designers can rely on for a variety of power switching needs.
