DMN2019UTS-13

Part No DMN2019UTS-13
Manufacturer Diodes Incorporated
Catalog Transistors - FETs, MOSFETs - RF
Description Low On-Resistance
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
FET Type 2 N-Channel (Dual) Common Drain
FET Feature Logic Level Gate
Drain Source Voltage 20V
Current - Continuous Drain (Id) @ 25°C 5.4A
Rds On (Maximum) @ Id, Vgs 18.5 mOhm @ 7A, 10V
Vgs(th) (Maximum) @ Id 950mV @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 8.8nC @ 4.5V
Input Capacitance (Ciss) (Maximum) @ Vds 143pF @ 10V
Power - Max 780mW
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Package 8-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 8-TSSOP
Win Source Part Number 1168120-DMN2019UTS-13
Manufacturer Homepage www.diodes.com
Family Name DMN2019UTS
Introduction Date October 07, 2011
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DMN2019UTS-13 CAD Model

Description

The DMN2019UTS-13 is a high-performance, N-Channel enhancement mode Field Effect Transistor (FET) brought to you by Diodes Incorporated. This MOSFET is designed to deliver efficient power control and switching functionalities in a wide array of electronic applications. Its compact form factor and robust design make it suitable for high-density power management systems where space is at a premium.

Key Features

  • Low On-Resistance: The DMN2019UTS-13 boasts a low on-resistance which significantly reduces conduction losses, leading to higher efficiency in electronic circuits.
  • High-Speed Switching: With its fast switching capabilities, this MOSFET is ideal for high-speed applications, ensuring minimal delay in response times.
  • Low Threshold Voltage: The low threshold voltage feature of the DMN2019UTS-13 allows for operation at lower voltages, making it versatile for various applications.
  • Low Input Capacitance: Reduced input capacitance minimizes drive losses and makes the MOSFET easier to drive, saving on additional driver circuitry costs.
  • High Thermal Performance: The device is encapsulated in a thermally efficient package that enhances heat dissipation, ensuring reliability even under high-temperature operating conditions.

Applications

The DMN2019UTS-13 is suitable for a range of applications, including:

  • Power Management
  • Load Switch
  • Battery Protection
  • DC-DC Converters
  • Motor Control Circuits

Technical Specifications

The DMN2019UTS-13 comes with the following specifications:

  • Drain-Source Voltage (VDS): 20V
  • Continuous Drain Current (ID): 6.5A
  • Power Dissipation (PD): 1.25W
  • Operating Temperature Range: -55°C to +150°C
  • Package: SOT-23

With its impressive efficiency, reliability, and versatility, the DMN2019UTS-13 from Diodes Incorporated stands as an excellent choice for designers looking to optimize their power control systems.
