MMBT4124-7-F

Part No MMBT4124-7-F
Manufacturer Diodes Incorporated
Catalog Transistors (BJT) - Single
Description TRANS NPN 25V 0.2A SMD SOT23-3
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 200mA
VCEO Maximum Collector-Emitter Breakdown Voltage 25V
Max Vce (sat) 300mV @ 5mA, 50mA
Collector Cut-off Current(Max) 50nA (ICBO)
Typical Gain (hFE) (Min) 120 @ 2mA, 1V
Maximum Power Dissipation 300mW
Frequency - Transition 300MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 023758-MMBT4124-7-F
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MMBT4124-7-F CAD Model

Description

Product Overview: MMBT4124-7-F by Diodes Incorporated

The MMBT4124-7-F from Diodes Incorporated is a high-performance NPN bipolar junction transistor (BJT) designed for use in a wide range of electronic applications. This versatile transistor is housed in a compact SOT-23 surface-mount package, making it suitable for space-constrained designs. Its small form factor is complemented by its robust electrical characteristics, which make it an excellent choice for switching and amplification purposes.

Key Features

  • Type: NPN Bipolar Junction Transistor (BJT)
  • Package: SOT-23 surface-mount package for compact design
  • Collector-Emitter Voltage (Vceo): 25V, which allows it to handle moderate voltage applications
  • Collector Current (Ic): 200mA, providing sufficient current for a variety of circuits
  • Power Dissipation (Pd): 350mW, ensuring reliable operation under normal conditions
  • DC Current Gain (hFE): High hFE value, ensuring efficient current amplification
  • Transition Frequency (ft): 300MHz, making it suitable for high-frequency applications
  • Operating Temperature Range: -55°C to +150°C, providing reliability across a wide range of environmental conditions

Applications

The MMBT4124-7-F is ideal for a variety of applications, including but not limited to:

  • Signal amplification in audio and video equipment
  • Switching applications in consumer electronics
  • Driver stages in amplifiers
  • Power management in portable devices
  • Control circuits in embedded systems

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the MMBT4124-7-F is no exception. This product is manufactured to meet high standards of performance and reliability, ensuring that it meets the needs of demanding electronic systems. With its robust design and Diodes Incorporated's reputation for quality, the MMBT4124-7-F is an excellent choice for designers seeking a reliable NPN transistor for their next project.

For detailed specifications and application notes, designers should consult the MMBT4124-7-F datasheet provided by Diodes Incorporated.
