Diodes Incorporated MMST3904-7-F NPN Transistor

The MMST3904-7-F from Diodes Incorporated is a high-quality NPN bipolar junction transistor (BJT) that is designed to offer excellent performance in a wide range of electronic applications. This versatile component is well-suited for amplification and switching purposes, making it a valuable part of any electronic enthusiast's or professional's inventory.

Constructed with Diodes Incorporated's precise manufacturing processes, the MMST3904-7-F ensures reliable and consistent performance. The device comes in a compact SOT-323 package, which is ideal for space-constrained applications. Despite its small size, it offers robust characteristics that make it suitable for high-density PCB designs.

Key Features:

• Type: NPN bipolar junction transistor (BJT)
• Package: SOT-323
• Collector-Emitter Voltage (Vceo): 40V
• Collector-Base Voltage (Vcbo): 60V
• Emitter-Base Voltage (Vebo): 6V
• Collector Current (Ic): 200mA
• Power Dissipation (Pd): 200mW
• DC Current Gain (hFE): 100 to 300
• Operating and Storage Junction Temperature Range: -55°C to +150°C

The MMST3904-7-F is designed to offer low noise operation, which is particularly important in audio amplifiers and signal processing applications. With a decent current gain (hFE) range, it can be used effectively in both low and moderate current applications.

Due to its high collector-emitter voltage and collector-base voltage, the MMST3904-7-F can handle moderate voltage applications while maintaining stability and reliability. The device's power dissipation capability ensures that it can handle continuous operation without overheating, provided that proper thermal management practices are observed.

Whether you're designing a new circuit or replacing a component in an existing one, the MMST3904-7-F offers the performance and quality that Diodes Incorporated is known for. Its robustness and versatility make it an excellent choice for a wide range of electronic projects, including but not limited to signal amplification, switching, and general-purpose use in commercial and industrial electronic equipment.

In summary, the MMST3904-7-F transistor is a testament to Diodes Incorporated's commitment to providing high-quality, reliable components for the electronics industry.
