The ZVNL110GTA is a high-performance, low-threshold N-channel enhancement-mode MOSFET manufactured by Diodes Incorporated. This device is designed to deliver efficient power control and switching applications in a compact SOT-223 package. With its advanced technology, the ZVNL110GTA provides an optimal solution for a wide range of applications, including power management, load switching, and motor control.
Key Features
- Low On-Resistance: The ZVNL110GTA boasts an extremely low on-resistance, which enhances its efficiency by minimizing power loss during operation.
- Low Threshold Voltage: This MOSFET operates at a low threshold voltage, making it suitable for low-voltage applications and ensuring that it can be driven by logic-level voltages.
- High-Speed Switching: Designed for fast switching applications, the ZVNL110GTA can switch on and off rapidly, which is crucial for high-frequency circuits.
- High Continuous Drain Current: The device supports a high continuous drain current, providing robust performance for high-power applications.
Applications
The versatility of the ZVNL110GTA allows it to be employed in a variety of applications. It is commonly used in:
- Power management systems
- DC/DC converters
- Battery powered devices
- Motor control circuits
- Load switching
Specifications
Parameter
Value
Package
SOT-223
Threshold Voltage (Typical)
1.0V
Drain-Source Voltage (Vds)
100V
Continuous Drain Current (Id)
500mA
On-Resistance (Rds on)
5 Ohm
Quality and Reliability
Diodes Incorporated is committed to providing high-quality products. The ZVNL110GTA MOSFET is produced with rigorous quality control processes to ensure reliability and performance in all applications. It is also supported by Diodes Incorporated's technical expertise and customer service.
