Product Overview: ZXLD1360ET5TA by Diodes Incorporated

The ZXLD1360ET5TA is a high-efficiency, easy-to-use LED driver IC from Diodes Incorporated, designed to drive high-brightness LEDs with a constant current for reliable and consistent performance. This driver IC is suitable for a wide range of applications, including automotive lighting, general illumination, and backlighting for signs and displays.

Key Features

• Adjustable Output Current: The device allows for an adjustable output current up to 1A, which can be set using a single external resistor. This feature provides flexibility in controlling the brightness of the connected LEDs.
• Wide Input Voltage Range: With an input voltage range from 7V to 30V, the ZXLD1360ET5TA can accommodate various power supplies, making it versatile for different application requirements.
• High Efficiency: The LED driver operates with high efficiency, which can exceed 90%, reducing energy consumption and heat generation, thereby extending the life of the LEDs.
• Thermal Protection: The device includes thermal shutdown protection, which safeguards the IC and the LEDs from damage due to excessive heat.
• PWM and Analog Dimming: It supports both PWM (Pulse Width Modulation) and analog dimming, offering precise control over the light output for dynamic lighting effects or power saving.

Applications

• Automotive exterior and interior lighting
• Architectural lighting
• LED backlights for LCD TVs and monitors
• Street lighting
• Commercial and residential lighting solutions

Product Specifications

The ZXLD1360ET5TA comes in a compact TSOT25 package, providing a space-saving solution for PCB layouts. It has an integrated switch with a typical R<sub>DS(ON) of 0.2Ω, contributing to its high efficiency. The device also features a low shutdown current and an LED open-circuit detection, enhancing the safety and reliability of the overall system.

Whether you're designing a sophisticated automotive lighting system or a simple, efficient backlight, the ZXLD1360ET5TA from Diodes Incorporated offers a versatile and reliable solution for driving high-brightness LEDs.
