PSOT36 Real Image
Same model may have multiple batches, images only for reference.

PSOT36

Part No PSOT36
Manufacturer DIOTEC Electronics Corporation
Catalog TVS - Diodes
Description TVS DIODE 36VWM 76.8VC SOT23-3
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr DIOTEC Electronics Corporation
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 36V
Voltage - Breakdown (Min) 40V
Voltage - Clamping (Max) @ Ipp 76.8V
Current - Peak Pulse (10/1000µs) 9A (8/20µs)
Power - Peak Pulse 500W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 80pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3 (TO-236)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
HTSUS 8541.10.0000
Win Source Part Number 657523-PSOT36
Ultra Librarian 3D Model Ultra Librarian PSOT36 CAD Model

Description

The PSOT36 is a unidirectional zener diode with a reverse standoff voltage of 36V and a breakdown voltage of 40V.

  • Clamping Voltage: 76.8V @ peak pulse power of 500W
  • Package: TO-236-3, SC-59, SOT-23-3
  • Manufacturer: DIOTEC Electronics Corporation
  • Status: Active
