Same model may have multiple batches, images only for reference.

US2D

Name: US2D
Brand: DIOTEC Electronics Corporation
SKU: 695525
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	US2D
Manufacturer	DIOTEC Electronics Corporation
Catalog	Diodes, Rectifiers - Single
Description	DIODE UFR SMB 200V 2A / Diode 200 V 2A Surface Mount DO-214AA (SMB)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	DIOTEC Electronics Corporation
Package	Tape & Reel
Product Status	Active
Technology	Standard
Voltage - DC Reverse (Vr) (Max)	200 V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Max) @ If	1 V @ 2 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	50 ns
Current - Reverse Leakage @ Vr	5 µA @ 200 V
Mounting Type	Surface Mount
Package / Case	DO-214AA, SMB
Supplier Device Package	DO-214AA (SMB)
Operating Temperature - Junction	-50°C ~ 150°C
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
HTSUS	8541.10.0000
Win Source Part Number	695525-US2D
Ultra Librarian 3D Model	Ultra Librarian US2D CAD Model

Alternative Products

Description

The US2D is a fast recovery rectifier diode that is widely used in various electronic applications.

Maximum Reverse Voltage (Vr): 200V
Average Rectified Current (Io): 2A
Forward Voltage (Vf): 1V @ 2A
Reverse Recovery Time (trr): 50ns
Package: Surface Mountable DO-214AA (SMB)
Package: Tape and Reel
Standard Quantity: 3,000 pcs
Operating Temperature Range: -50°C to 150°C
Manufacturer: DIOTEC Electronics Corporation
Product Status: Active
