Products specifications Report Issue?

Category Inductors, Coils, Chokes - Arrays, Signal Transformers
Mfr Eaton Bussmann
Series OCTA-PAC®
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Obsolete
Number of Coils 2
Inductance - Connected In Parallel 4.9 µH
Inductance - Connected In Series 19.6 µH
Tolerance ±20%
Current Rating - Parallel 4.4 A
Current Rating - Series 2.2 A
DC Resistance (DCR) - Parallel 14mOhm Max
DC Resistance (DCR) - Series 56mOhm Max
Shielding Unshielded
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.550" L x 0.550" W (13.97mm x 13.97mm)
Height 0.250" (6.35mm)
Standard Package 600 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 580994-CTX5-4
Ultra Librarian 3D Model Ultra Librarian CTX5-4 CAD Model

Description

The 580994-CTX5-4 is a part of the OCTA-PAC® series of inductors, coils, and chokes. It is a signal transformer designed for use in electronic circuits.

  • Package: Tape and Reel
  • Size: 0.550" L x 0.550" W (13.97mm x 13.97mm)
  • Height: 0.250" (6.35mm)
  • Number of Coils: 2
  • Inductance (Series): 19.6 µH
  • Inductance (Parallel): 4.9 µH
  • Current Rating (Series): 2.2 A
  • Current Rating (Parallel): 4.4 A
  • DC Resistance (Series): 56mOhm max
  • DC Resistance (Parallel): 14mOhm max
  • Operating Temperature: -40°C to 85°C
  • Manufacturer: Eaton Bussmann
  • Package: Nonstandard
