FWP-80B Real Image
Same model may have multiple batches, images only for reference.

FWP-80B

Part No FWP-80B
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE CARTRIDGE 80A 700VAC/VDC  /  80A 700 V AC 700 V DC Fuse Cartridge Bolt Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Series FWP
Package Bulk
Mounting Type Bolt Mount
Fuse Type Cartridge
Current Rating (Amps) 80A
Voltage Rating - AC 700 V
Voltage Rating - DC 700 V
Applications Electrical, Industrial
Approval Agency CE, CSA, UR
Breaking Capacity @ Rated Voltage 200kA AC, 50kA DC
Package / Case Cylindrical, Blade Terminal (Bolt)
Dimension 0.947" Dia x 2.594" L (24.05mm x 65.89mm)
Melting I2t 360
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.10.0040
Standard Package 1
Win Source Part Number 1083703-FWP-80B
Ultra Librarian 3D Model Ultra Librarian FWP-80B CAD Model

Description

The Eaton - Bussmann Electrical Division FWP-80B is an electrical, specialty fuse that falls under the circuit protection category.

  • Voltage Rating: 700V AC and DC
  • Current Rating: 80A
  • Breaking Capacity: 200kA AC and 50kA DC @ Rated Voltage
  • Package: Cylindrical, Blade Terminal (Bolt)
