The EN5360DC is a high-efficiency PowerSoC (Power System on a Chip) DC-DC step-down converter from Enpirion (now Intel). It integrates all the necessary components for a complete power solution into a small package, including the inductor, MOSFETs, and control circuitry. Being an end-of-life product, availability may be limited, and replacement parts are usually recommended for new designs.

Applications:

• Point-of-Load (POL) Converters
• FPGA Power Supplies
• ASIC Power Supplies
• Memory Power Supplies (DDR, etc.)
• Embedded Systems

Features:

• High Efficiency: Up to 95% peak efficiency.
• Integrated Inductor: Reduces board space and simplifies design.
• Small Footprint: Minimizes solution size.
• Programmable Output Voltage: Allows for flexible voltage settings.
• Overcurrent Protection: Protects the device and load from damage.
• Thermal Shutdown: Prevents overheating.
• Soft-Start: Limits inrush current during startup.

Benefits:

• Simplified Design: Reduces the number of external components needed, saving time and effort.
• High Efficiency: Minimizes power losses, resulting in longer battery life and reduced heat generation.
• Small Size: Enables compact designs for space-constrained applications.
• Robust Protection: Protects the device and load from potential damage.
• Improved Reliability: Integrated design enhances reliability compared to discrete solutions.

Additional Details:

The EN5360DC operates over a wide input voltage range and provides a stable and regulated output voltage. Its integrated design simplifies PCB layout and reduces the risk of component placement errors. The device's high efficiency and low thermal resistance enable it to operate at high ambient temperatures without derating. It's important to note that, as an end-of-life part, finding alternative solutions for new designs is highly advisable.
