B78108E1473J009

Part No B78108E1473J009
Manufacturer EPCOS (TDK)
Catalog Fixed Inductors
Description FIXED IND 47UH 950MA 680 MOHM TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 47 µH
Tolerance ±5%
Current Rating (Amps) 950 mA
Current - Saturation (Isat) 870mA
Shielding Unshielded
DC Resistance (DCR) 680mOhm Max
Q @ Freq 40 @ 796kHz
Frequency - Self Resonant 8MHz
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Through Hole
Case / Package Axial
Size / Dimension 0.157" Dia x 0.374" L (4.00mm x 9.50mm)
Package Cut Tape (CT)
Supply and Demand Status Normal
Win Source Part Number 1530358-B78108E1473J009
Ultra Librarian 3D Model Ultra Librarian B78108E1473J009 CAD Model
