B82462A4223K Real Image
Same model may have multiple batches, images only for reference.

B82462A4223K

Part No B82462A4223K
Manufacturer EPCOS (TDK)
Catalog Fixed Inductors
Description FIXED IND 22UH 800MA 260 MOHM
Datasheet
B82462A4223K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer EPCOS (TDK)
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 22μH
Tolerance ±10%
Current Rating 800mA
Current - Saturation 1.28A
DC Resistance (DCR) 260 mOhm Max
Frequency - Self Resonant 21MHz
Temperature Range - Operating -55°C to 150°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.118" (3.00mm)
Win Source Part Number 000134-B82462A4223K
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian B82462A4223K CAD Model

Description

Product Description

The B82462A4223K offers outstanding inductive performance, suited for a wide array of technological applications needing precise control of electrical characteristics.

Applications

  • Medical Equipment
  • High-efficiency LED Drivers
  • Audio and Video Devices
  • Renewable Energy Systems

Features and Benefits

  • Inductance: 22mH
  • Excellent Quality Factor
  • Broad Frequency Response
  • Minimal Acoustic Noise Emission
  • RoHS compliant

Additional Details

Ideal for high-performance settings, this inductor is crafted to support optimal functionality while maintaining energy efficiency, critical for evolving electronic demands.
