The M12L2561616AA1AM is a high-performance 256Mb SDRAM (Synchronous Dynamic Random-Access Memory) chip manufactured by ESMT. This memory component is designed for applications requiring fast data access and low power consumption. It operates at standard SDRAM voltages and provides a versatile solution for embedded systems, networking devices, and various consumer electronics.

Applications:

• Embedded Systems
• Networking Devices (Routers, Switches)
• Consumer Electronics (Set-Top Boxes, Digital TVs)
• Industrial Control Systems
• Gaming Consoles

Features:

• Capacity: 256Mb (16Mb x 16)
• Organization: Configured as 16 Meg x 16 bits
• Interface: Standard SDRAM interface
• Clock Rate: Typically supports clock rates up to 133MHz
• Power Supply: Operates at standard SDRAM voltage (e.g., 3.3V)
• Refresh: Auto and Self Refresh modes available
• Package: Available in various package options including TSOP and BGA
• Temperature Range: Supports commercial and industrial temperature ranges

Benefits:

• High Performance: Provides fast data access, improving system responsiveness.
• Low Power Consumption: Efficient design minimizes power usage, extending battery life in portable devices.
• Reliability: Designed for stable and reliable operation in demanding environments.
• Compact Size: Available in compact packages for space-constrained applications.
• Cost-Effective: Provides a balance of performance and cost.

Additional Details:

The M12L2561616AA1AM uses a synchronous interface to achieve high-speed data transfers. It supports burst read and write operations, allowing for efficient data handling. The chip includes features such as auto-refresh and self-refresh modes to manage power consumption and data retention. Its compatibility with standard SDRAM controllers simplifies integration into existing systems. The precise timings and electrical characteristics can be found in the device datasheet provided by ESMT.
