1N4148WT Real Image 1N4148WT real image19 1N4148WT Real Image1 1N4148WT Real Image2 1N4148WT Real Image3
Same model may have multiple batches, images only for reference.
1N4148WT Real Image 1N4148WT real image19 1N4148WT Real Image1 1N4148WT Real Image2 1N4148WT Real Image3
1N4148WT Real Image 1N4148WT real image19 1N4148WT Real Image1 1N4148WT Real Image2 1N4148WT Real Image3
Same model may have multiple batches, images only for reference.

1N4148WT

Part No 1N4148WT
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 75V 200MA SOD523F
Datasheet
1N4148WT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 5μA @ 75V
Capacitance @ Vr, F 5pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-523F
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 095827-1N4148WT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing
Quantity per package 8k pcs
Ultra Librarian 3D Model Ultra Librarian 1N4148WT CAD Model

Description

1N4148WT - Rapid Response Signal Diode

The 1N4148WT is tailored for rapid response applications, offering high performance with minimal power loss. It is perfect for designs where space and efficiency are key priorities.

Features and Benefits

  • Rapid Signal Transition: Ensures quick operation for time-sensitive circuits.
  • SMD Configuration: Perfect for compact device installations.
  • Low Forward Voltage: Reduces power consumption effectively.

Applications

  • High-Speed Data Interfaces
  • Telecommunication Systems
  • Switching Power Supplies
  • Phase Detection in Signals
  • Voltage Regulation Circuits

The 1N4148WT aids in optimizing electronics for both speed and space, delivering performance in modern technical needs.
