BD1396STU Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

BD1396STU

Part No BD1396STU
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 80V 1.5A TO-126
Datasheet
BD1396STU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Transistor Polarity NPN
Maximum Current Collector 1.5A
VCEO Maximum Collector-Emitter Breakdown Voltage 80V
Max Vce (sat) 500mV @ 50mA, 500mA
Collector Cut-off Current(Max) 100nA (ICBO)
Typical Gain (hFE) (Min) 40 @ 150mA, 2V
Maximum Power Dissipation 1.25W
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-126
Win Source Part Number 200956-BD1396STU
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1,920
Ultra Librarian 3D Model Ultra Librarian BD1396STU CAD Model

Description

Product Description

The BD1396STU is a reliable NPN transistor, notable for its robustness in medium-power applications, making it a popular choice among electronics professionals.

Features and Benefits

  • Durable construction: Withstands demanding environments and frequent use.
  • Efficient power handling: Optimized for energy-dependent circuits.
  • High thermal endurance: Maintains performance across varying temperatures.

Applications

  • DC motor control systems
  • Lighting control circuits
  • Signal amplifiers

Additional Details: The BD1396STU is engineered to provide consistent performance, ensuring stability and reliability for a myriad of electronic applications.
