FAN1086S5X Real Image
Same model may have multiple batches, images only for reference.

FAN1086S5X

Part No FAN1086S5X
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR FIXED LDO REG / Linear Voltage Regulator IC Positive Fixed 1 Output 1.5A SOT-223-4
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Fairchild/ON Semiconductor
Package Bulk
Product Status Obsolete
Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 7.5V
Voltage - Output (Min/Fixed) 5V
Voltage Dropout (Max) 1.5V @ 1.5A
Current - Output 1.5A
Current - Quiescent (Iq) 13 mA
PSRR 72dB (120Hz)
Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Supplier Device Package SOT-223-4
Standard Package 2,500 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 590556-FAN1086S5X
Ultra Librarian 3D Model Ultra Librarian FAN1086S5X CAD Model

Description

The 590556-FAN1086S5X is a linear voltage regulator from Fairchild/ON Semiconductor.

  • Category: Integrated Circuits (ICs) Power Management (PMIC)
  • Output Type: Fixed
  • Voltage Output: 5V
  • Maximum Input Voltage: 7.5V
  • Current Output: Up to 1.5A
  • Package Type: TO-261-4, TO-261AA
  • Device Package: SOT-223-4
  • Operating Temperature: 0°C to 125°C
  • Protection Features: Over Current and Over Temperature
  • PSRR: 72dB @ 120Hz
  • Product Status: Obsolete
  • Current Quiescent: 13mA
  • REACH: Unaffected
  • ECCN: EAR99
