FDA24N50 Real Image FDA24N50 Real Image
Same model may have multiple batches, images only for reference.
FDA24N50 Real Image FDA24N50 Real Image
FDA24N50 Real Image FDA24N50 Real Image
Same model may have multiple batches, images only for reference.

FDA24N50

Part No FDA24N50
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 500V 24A TO-3PN
Datasheet
FDA24N50 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 500V
Continuous Drain Current at 25°C 24A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 85nC @ 10V
Max Input Capacitance 4150pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 270W (Tc)
Maximum Rds On at Id,Vgs 190 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-3PN
Dimension TO-3P-3, SC-65-3
Win Source Part Number 1037943-FDA24N50
Popularity Medium
Supply and Demand Status Balance
Quantity per package 450
Ultra Librarian 3D Model Ultra Librarian FDA24N50 CAD Model

Description

The Fairchild/ON Semiconductor 1037943-FDA24N50 is an N-channel MOSFET with a power dissipation of 270W (Tc).

  • Power Dissipation: 270W (Tc)
  • Drive Voltage: 10V for max Rds on and min Rds on
  • Package: TO-3PN
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Drain-Source Breakdown Voltage: 500V
  • Continuous Drain Current: 24A (Tc)
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Maximum Gate Charge: 85nC @ 10V
  • Maximum Input Capacitance: 4150pF @ 25V
  • Supplied: tube/rail package with a quantity of 450
