FDA59N30 Real Image FDA59N30 Real Image1 FDA59N30 Real Image2
Same model may have multiple batches, images only for reference.
FDA59N30 Real Image FDA59N30 Real Image1 FDA59N30 Real Image2
FDA59N30 Real Image FDA59N30 Real Image1 FDA59N30 Real Image2
Same model may have multiple batches, images only for reference.

FDA59N30

Part No FDA59N30
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 300V 59A TO-3P / Trans MOSFET N-CH 300V 59A 3-Pin(3+Tab) TO-3P Tube
Datasheet
FDA59N30 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 300V
Continuous Drain Current at 25°C 59A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 100nC @ 10V
Max Input Capacitance 4670pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 500W (Tc)
Maximum Rds On at Id,Vgs 56 mOhm @ 29.5A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-3PN
Dimension TO-3P-3, SC-65-3
Win Source Part Number 1037948-FDA59N30
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 450
Family Name FDA59N30
Introduction Date July 07, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian FDA59N30 CAD Model

Description

The FDA59N30 is an N-channel MOSFET from Fairchild/ON Semiconductor.

  • Maximum Power Dissipation: 500W
  • Continuous Drain Current: 59A
  • Gate-Source Threshold Voltage: 5V
  • Maximum Gate-Source Voltage: ±30V
  • Package Type: TO-3PN
  • Operating Temperature Range: -55°C to 150°C
