FDMC2523P

Name: FDMC2523P
Brand: Fairchild/ON Semiconductor
SKU: 129340
Availability: InStock
Rating: 4.93 (63 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDMC2523P
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 150V 3A MLP 3.3SQ
Datasheet	FDMC2523P Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	150V
Continuous Drain Current at 25°C	3A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	5V @ 250μA
Max Gate Charge	9nC @ 10V
Max Input Capacitance	270pF @ 25V
Maximum Gate-Source Voltage	±30V
Power Dissipation (Max)	42W (Tc)
Maximum Rds On at Id,Vgs	1.5 Ohm @ 1.5A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-MLP (3.3x3.3)
Dimension	8-PowerWDFN
Win Source Part Number	112819-FDMC2523P
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Motor Drive & Control, Industrial
Family Name	FDMC2523P
Introduction Date	May 11, 2006
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2024
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian FDMC2523P CAD Model

Alternative Products

Description

The FDMC2523P is a P-channel MOSFET from Fairchild/ON Semiconductor that features a surface mount device (SMD) mounting style.

Continuous Drain Current (Max): 3A (Tc)
Drain-Source Breakdown Voltage: 150V
Rds On (Max) @ Id,Vgs: 1.5 Ohm
Package: 8-MLP (3.3x3.3)
Temperature Range: -55°C to 150°C (TJ)
Compliance: Halogen-Free
Popularity: High
Supply and Demand: Balanced
Packaging: Reel
Package Quantity: 3k pcs
