FDMC3612 Real Image FDMC3612 real image4060
Same model may have multiple batches, images only for reference.
FDMC3612 Real Image FDMC3612 real image4060
FDMC3612 Real Image FDMC3612 real image4060
Same model may have multiple batches, images only for reference.

FDMC3612

Part No FDMC3612
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 8-MLP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 3.3A (Ta), 16A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 21nC @ 10V
Max Input Capacitance 880pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.3W (Ta), 35W (Tc)
Maximum Rds On at Id,Vgs 110 mOhm @ 3.3A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-MLP (3.3x3.3)
Dimension 8-PowerWDFN
Win Source Part Number 066975-FDMC3612
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDMC3612 CAD Model

Description

The FDMC3612 is an N-Channel MOSFET manufactured by Fairchild/ON Semiconductor.

  • Power Dissipation (Max): 2.3W (Ta), 35W (Tc)
  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current (at 25°C): 3.3A (Ta), 16A (Tc)
  • Maximum Rds On (at Id,Vgs): 110 mOhm @ 3.3A, 10V
  • Maximum Gate Charge: 21nC @ 10V
  • Maximum Input Capacitance: 880pF @ 50V
  • Package: 8-MLP (3.3x3.3)
  • Quantity per Package: 3k pcs
