Same model may have multiple batches, images only for reference.

FDN352AP

Name: FDN352AP
Brand: Fairchild/ON Semiconductor
SKU: 129562
Availability: InStock
Rating: 4.85 (59 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDN352AP
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 1.3A SSOT-3
Datasheet	FDN352AP Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	1.3A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Gate Charge	1.9nC @ 4.5V
Max Input Capacitance	150pF @ 15V
Maximum Gate-Source Voltage	±25V
Power Dissipation (Max)	500mW (Ta)
Maximum Rds On at Id,Vgs	180 mOhm @ 1.3A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SuperSOT-3
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	016108-FDN352AP
Family Name	FDN352AP
Introduction Date	April 21, 2005
ECCN	EAR99
Country of Origin	Israel, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Computers & Computer Peripherals, Power Management
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian FDN352AP CAD Model

Description

The FDN352AP is a P-channel MOSFET from Fairchild/ON Semiconductor. The MOSFET has a supply and demand balance and is active.

Maximum Power Dissipation: 500mW
Continuous Drain Current: 1.3A @ 25°C
Operating Temperature: -55°C to 150°C (TJ)
Gate-Source Threshold Voltage: 2.5V @ 250μA
Package: SuperSOT-3
Quantity: 3k pcs per package
