FDP050AN06A0 Fairchild/ON Semiconductor FDP050AN06A0 Real Image FDP050AN06A0 real image
Same model may have multiple batches, images only for reference.
FDP050AN06A0 Fairchild/ON Semiconductor FDP050AN06A0 Real Image FDP050AN06A0 real image
FDP050AN06A0 Fairchild/ON Semiconductor FDP050AN06A0 Real Image FDP050AN06A0 real image
Same model may have multiple batches, images only for reference.

FDP050AN06A0

Part No FDP050AN06A0
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 80A TO-220AB
Datasheet
FDP050AN06A0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 18A (Ta), 80A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 80nC @ 10V
Max Input Capacitance 3900pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 245W (Tc)
Maximum Rds On at Id,Vgs 5 mOhm @ 80A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220-3
Dimension TO-220-3
Win Source Part Number 067011-FDP050AN06A0
Popularity Medium
Supply and Demand Status Limited
Quantity per package 800
Ultra Librarian 3D Model Ultra Librarian FDP050AN06A0 CAD Model

Description

The Fairchild/ON Semiconductor 067011-FDP050AN06A0 is a MOSFET technology-based electronic component with a N-Channel polarity.

  • Application: Discrete Semiconductor Products
  • Maximum Power Dissipation: 245W (Tc)
  • Packaging: Tube/Rail
  • Mounting: Through Hole
  • Drive Voltage: 6V, 10V (Max Rds On, Min Rds On)
  • Temperature Range: -55°C to 175°C (TJ)
  • Supply and Demand: Limited
  • Package Quantity: 800 pieces
