FQA8N100C Real Image FQA8N100C Real Image
Same model may have multiple batches, images only for reference.
FQA8N100C Real Image FQA8N100C Real Image
FQA8N100C Real Image FQA8N100C Real Image
Same model may have multiple batches, images only for reference.

FQA8N100C

Part No FQA8N100C
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 1000V 8A TO-3P
Datasheet
FQA8N100C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 1000V
Continuous Drain Current at 25°C 8A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 70nC @ 10V
Max Input Capacitance 3220pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 225W (Tc)
Maximum Rds On at Id,Vgs 1.45 Ohm @ 4A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-3PN
Dimension TO-3P-3, SC-65-3
Win Source Part Number 1039570-FQA8N100C
Popularity Medium
Supply and Demand Status Sufficient
Quantity per package 450
Ultra Librarian 3D Model Ultra Librarian FQA8N100C CAD Model

Description

The FQA8N100C is an N-channel MOSFET from Fairchild/ON Semiconductor.

  • Power Dissipation (Max): 225W (Tc)
  • Drain-Source Breakdown Voltage: 1000V
  • Rds On (Max) @ Id, Vgs: 1.45 Ohm @ 4A, 10V
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Gate Charge (Max): 70nC @ 10V
  • Input Capacitance (Max): 3220pF @ 25V
  • Package: TO-3PN
  • Mounting Type: Through Hole
  • Drive Voltage: 10V
  • Temperature Range: -55°C to 150°C (TJ)
  • Popularity: Medium
  • Supply and Demand Status: Sufficient
  • Package Quantity: 450
