The FQB47P06 is a P-Channel enhancement mode power MOSFET from Fairchild Semiconductor (now ON Semiconductor), optimized for low on-resistance and fast switching speeds. This MOSFET is suitable for a variety of power management and switching applications where efficiency is critical.

Applications

• Load switching
• Power management in portable devices
• DC-DC converters
• Battery management systems
• Motor control applications

Features

• P-Channel MOSFET
• Low on-resistance (RDS(on))
• High drain current capability
• Fast switching speed
• Avalanche energy rated

Benefits

• Increased power efficiency
• Reduced power dissipation
• Improved thermal performance
• Simplified drive circuitry

Specifications

The FQB47P06 has a drain-source voltage (VDS) of -60V, a gate-source voltage (VGS) of ±20V, and a continuous drain current (ID) of -47A. The on-resistance (RDS(on)) is typically 0.021 Ohms at VGS = -10V. It comes in a TO-263 (D2PAK) package, which provides good thermal characteristics for surface mounting. The device is designed for efficient power handling and fast switching in demanding applications. Its avalanche energy rating ensures robustness against transient voltage spikes.
