FSBB20CH60C Real Image FSBB20CH60C Real Image1 FSBB20CH60C Real Image2
Same model may have multiple batches, images only for reference.
FSBB20CH60C Real Image FSBB20CH60C Real Image1 FSBB20CH60C Real Image2
FSBB20CH60C Real Image FSBB20CH60C Real Image1 FSBB20CH60C Real Image2
Same model may have multiple batches, images only for reference.

FSBB20CH60C

Part No FSBB20CH60C
Manufacturer Fairchild/ON Semiconductor
Catalog Power Drivers - Modules
Description Smart Power Module
Datasheet
FSBB20CH60C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Series Motion SPM 3
Type IGBT
Configuration 3 Phase
Current 20A
Voltage 600V
Voltage - Isolation 2500Vrms
Package 27-PowerDIP Module (1.205", 30.60mm)
Win Source Part Number 1175885-FSBB20CH60C
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Quantity per package 60
Family Name FSBB20CH60C
Introduction Date February 11, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian FSBB20CH60C CAD Model

Description

The FSBB20CH60C from Fairchild/ON Semiconductor is a 3-phase IGBT transistor suitable for use in various electronic applications.

  • Applications: Power supplies, DC-DC converters, and motor control circuits
  • Maximum Voltage: 600V
  • Current: 20A
  • Voltage Isolation: 2500Vrms
  • Package: 27-PowerDIP module
  • Supply and Demand: Limited
  • Package Quantity: 60
