HGTG11N120CND

Part No HGTG11N120CND
Manufacturer Fairchild/ON Semiconductor
Catalog IGBTs - Single
Description Trans IGBT Chip N-CH 1200V 43A 298000mW 3-Pin(3+Tab) TO-247 Tube / IGBT 1200V 43A 298W TO247
Datasheet
HGTG11N120CND Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Not For New Designs
IGBT Type NPT
VCEO Maximum Collector-Emitter Breakdown Voltage 1200V
Maximum Current Collector 43A
Pulsed Collector Current 80A
Collector-emitter saturation voltage(Max) 2.4V @ 15V, 11A
Maximum Power Dissipation 298W
Total Switching Energy(Ets) 950μJ (on), 1.3mJ (off)
Input Type Standard
Gate Charge 100nC
Turn-on and Turn-off delay time 23ns/180ns
Testing Conditions 960V, 11A, 10 Ohm, 15V
Reverse Recovery Time (trr) 70ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247
Win Source Part Number 089265-HGTG11N120CND
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 450
Family Name HGTG11N120C
Introduction Date December 17, 2001
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian HGTG11N120CND CAD Model

Description

The HGTG11N120CND is an IGBT transistor manufactured by Fairchild/ON Semiconductor. It has a voltage breakdown of 1200V and a current rating of 43A. This component is widely used in power supply circuits, DC-DC converters, and motor control applications. It comes in a TO-247 package and is RoHS compliant.
