Same model may have multiple batches, images only for reference.
HSR412L Real Image
Same model may have multiple batches, images only for reference.

HSR412L

Part No HSR412L
Manufacturer Fairchild/ON Semiconductor
Catalog Solid State Relays
Description OPTOCOUPLER SSR 400V 6DIP
Datasheet
HSR412L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Fairchild/ON Semiconductor
Packaging Bulk
Status Obsolete(EOL)
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Max On Resistance 35 Ohm
Load Current 120mA
Voltage - Input 1.6VDC
Voltage - Load 0 to 400 V
Mounting Through Hole
Termination Style PC Pin
Case / Package 6-DIP
Relay Type Relay
Win Source Part Number 1044150-HSR412L
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HSR412L CAD Model

Description

The HSR412L is a single-pole single-throw (SPST-NO) relay that has a load current of 120mA and a voltage load range of 0 to 400V.

  • Load Current: 120mA
  • Voltage Load: 0 to 400V
  • On Resistance (Max): 35 Ohm
  • Package: 6-DIP
  • Mounting: Through Hole
  • Input Voltage: 1.6VDC
  • Termination Style: PC Pin
