KA7805AETU Fairchild/ON Semiconductor KA7805AETU Real Image1 KA7805AETU Real Image2
Same model may have multiple batches, images only for reference.
KA7805AETU Fairchild/ON Semiconductor KA7805AETU Real Image1 KA7805AETU Real Image2
KA7805AETU Fairchild/ON Semiconductor KA7805AETU Real Image1 KA7805AETU Real Image2
Same model may have multiple batches, images only for reference.

KA7805AETU

Part No KA7805AETU
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 1A TO220-3
Datasheet
KA7805AETU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 2V @ 1A (Typ)
Output Current 1A
Operating Supply Current 6mA
PSRR 68dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 2V @ 1A
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 205825-KA7805AETU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian KA7805AETU CAD Model

Description

The Fairchild/ON Semiconductor 205825-KA7805AETU is a through-hole mounted positive fixed regulator with a 5V fixed output voltage.

  • Voltage Dropout: 2V @ 1A
  • Maximum Input Voltage: 35V
  • Regulator Count: One regulator
  • Suitable for: Use in integrated circuits
  • Operating Temperature Range: 0°C to 125°C
  • Package: TO-220AB
  • Nominal Output Voltage: 5V
  • Dropout Voltage: 2V @ 1A (Typ)
  • Operating Supply Current: 6mA
  • Protection Features: Over temperature and short circuit protection
