KA78M05RTM Real Image KA78M05RTM Real Image1 KA78M05RTM Real Image2
Same model may have multiple batches, images only for reference.
KA78M05RTM Real Image KA78M05RTM Real Image1 KA78M05RTM Real Image2
KA78M05RTM Real Image KA78M05RTM Real Image1 KA78M05RTM Real Image2
Same model may have multiple batches, images only for reference.

KA78M05RTM

Part No KA78M05RTM
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.5A TO252-3
Datasheet
KA78M05RTM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 2V @ 500mA (TYP)
Output Current 500mA
Operating Supply Current 6mA
PSRR 80dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 2V @ 500mA
Mounting SMD (SMT)
Case / Package D-Pak
Win Source Part Number 018198-KA78M05RTM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian KA78M05RTM CAD Model

Description

The Fairchild/ON Semiconductor integrated circuit is a reliable and efficient product that can be used in various electronic devices.

  • Win Source Part Number: 018198-KA78M05RTM
  • Category: Integrated Circuits
  • Regulator Topology: Positive fixed voltage regulator
  • Maximum Input Voltage: 35V
  • Nominal Output Voltage: 5V
  • Dropout Voltage-Max: 2V @ 500mA
  • Packaging: D-Pak
  • Temperature Range: -40°C to 125°C
