The Fairchild/ON Semiconductor MMBF170 is a N-Channel MOSFET with a power dissipation of 300mW (Ta).

• Mounting Type: SMD (SMT)
• Drive Voltage (Max Rds On, Min Rds On): 10V
• Operating Temperature: -55°C to 150°C (TJ)
• Case/Package: SOT-23
• Dimension: TO-236-3, SC-59, SOT-23-3
• Drain-Source Breakdown Voltage: 60V
• Continuous Drain Current @ 25°C: 500mA (Ta)
• Gate-Source Threshold Voltage: 3V @ 1mA
• Max Input Capacitance: 40pF @ 10V
• Maximum Gate-Source Voltage: ±20V
• Maximum Rds On @ Id,Vgs: 5 Ohm @ 200mA, 10V
• Quantity per package: 3k pcs
