MOC3082SM Real Image MOC3082SM Real Image
Same model may have multiple batches, images only for reference.
MOC3082SM Real Image MOC3082SM Real Image
MOC3082SM Real Image MOC3082SM Real Image
Same model may have multiple batches, images only for reference.

MOC3082SM

Part No MOC3082SM
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Triac, SCR Output
Description 6-PIN DIP ZERO-CROSS OPTOISOLATORS TRIAC DRIVER OUTPUT (800 VOLT PEAK)
Datasheet
MOC3082SM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Voltage - Isolation 4170Vrms
Voltage - Off State 800V
Static dV/dt (Minimum) 600V/μs
Current - LED Trigger (Ift) (Maximum) 10mA
Current - Hold (Ih) 500μA (Typ)
Voltage - Forward (Vf) (Typ) 1.3V
Current - DC Forward (If) (Maximum) 60mA
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 6-SMD, Gull Wing
Manufacturer Package 6-SMD
Approvals UL
Win Source Part Number 1225822-MOC3082SM
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian MOC3082SM CAD Model

Description

The MOC3082SM is an optocoupler with a triac output that is used for interfacing between electronic devices and AC power circuits.

  • Output Type: Triac
  • Application: Interfacing between electronic devices and AC power circuits.
  • Operating Temperature: -40°C to 85°C
  • Voltage Rating: 800V
  • Forward Voltage: 1.3V
  • Isolation Voltage: 4170Vrms
  • Features: Zero-crossing circuit and a hold current of 500μA
  • Mounting: 6-SMD, Gull Wing package
  • Approval: UL approved
  • Category: Isolators
  • Supply and Demand: Limited
  • Popularity: Medium
