NC7SV86P5X Real Image NC7SV86P5X Real Image
Same model may have multiple batches, images only for reference.
NC7SV86P5X Real Image NC7SV86P5X Real Image
NC7SV86P5X Real Image NC7SV86P5X Real Image
Same model may have multiple batches, images only for reference.

NC7SV86P5X

Part No NC7SV86P5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE XOR 1CH 2-INP SC-70-5
Datasheet
NC7SV86P5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type XOR (Exclusive OR)
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 0.9 V to 3.6 V
Current - Quiescent (Max) 0.9μA
Current - Output High, Low 24mA, 24mA
Logic Level - Low 0.7 V to 0.8 V
Logic Level - High 1.6 V to 2 V
Max Propagation Delay @ V, Max CL 3.3ns @ 3V, 30pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 059880-NC7SV86P5X
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SV86P5X CAD Model

Description

The NC7SV86P5X is a XOR (Exclusive OR) integrated circuit manufactured by Fairchild/ON Semiconductor.

  • Packaging: reel
  • Circuit: one
  • Popularity: medium
  • Supply and demand status: balanced
  • Maximum propagation delay @ V, Max CL: 3.3ns @ 3V, 30pF
  • Current - quiescent (max): 0.9μA
  • Logic level - low: 0.7 V to 0.8 V
  • Logic level - high: 1.6 V to 2 V
  • Temperature range: -40°C to 85°C
  • Case/Package: SC-70-5 with a dimension of 5-TSSOP, SC-70-5, SOT-353
  • Supply voltage - operating: 0.9 V to 3.6 V
