NDT454P Fairchild/ON Semiconductor NDT454P Real Image NDT454P label picture
Same model may have multiple batches, images only for reference.
NDT454P Fairchild/ON Semiconductor NDT454P Real Image NDT454P label picture
NDT454P Fairchild/ON Semiconductor NDT454P Real Image NDT454P label picture
Same model may have multiple batches, images only for reference.

NDT454P

Part No NDT454P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 30V 5.9A 4-Pin(3+Tab) SOT-223 T/R / MOSFET P-CH 30V 5.9A SOT-223
Datasheet
NDT454P Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 5.9A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.7V @ 250μA
Max Gate Charge 40nC @ 10V
Max Input Capacitance 950pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 50 mOhm @ 5.9A, 10V
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 113992-NDT454P
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 4k pcs
Family Name NDT454P
Introduction Date August 06, 1997
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian NDT454P CAD Model

Description

The NDT454P is a P-Channel MOSFET transistor manufactured by Fairchild/ON Semiconductor.

  • Supply and Demand Status: Limited
  • Applications: Power management, switching, and amplification
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 5.9A
  • Operating Temperature Range: -65°C to 150°C
  • Mounting: SMD (SMT)
  • Package: SOT-223-4
