SI4435DY Fairchild/ON Semiconductor SI4435DY Real Image SI4435DY Real Image1 SI4435DY Real Image2
Same model may have multiple batches, images only for reference.
SI4435DY Fairchild/ON Semiconductor SI4435DY Real Image SI4435DY Real Image1 SI4435DY Real Image2
SI4435DY Fairchild/ON Semiconductor SI4435DY Real Image SI4435DY Real Image1 SI4435DY Real Image2
Same model may have multiple batches, images only for reference.

SI4435DY

Part No SI4435DY
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 8.8A 8-SOIC / Trans MOSFET P-CH 30V 8.8A 8-Pin SOIC T/R
Datasheet
SI4435DY Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 8.8A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 24nC @ 5V
Max Input Capacitance 1604pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 20 mOhm @ 8.8A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 028489-SI4435DY
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Quantity per package 2,500
Family Name Si4435DY
Introduction Date June 15, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SI4435DY CAD Model

Description

The Si4435DY is a P-channel MOSFET manufactured by Fairchild/ON Semiconductor.

  • Package: 8-SOIC
  • Dimension: 0.154 inches
  • Width: 3.90mm
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 8.8A @ 25°C
  • Gate-Source Threshold Voltage: 3V @ 250μA
  • Maximum Gate Charge: 24nC @ 5V
  • Maximum Rds On @ Id, Vgs: 20 mOhm @ 8.8A, 10V
  • ECCN: EAR99 compliant
  • Estimated EOL date: 2027
  • Supply and demand status: balanced
  • Package: 2,500
