MC9S08DZ60AMLH Real Image MC9S08DZ60AMLH Real Image2 MC9S08DZ60AMLH Real Image3 MC9S08DZ60AMLH Real Image4 MC9S08DZ60AMLH Real Image5
Same model may have multiple batches, images only for reference.
MC9S08DZ60AMLH Real Image MC9S08DZ60AMLH Real Image2 MC9S08DZ60AMLH Real Image3 MC9S08DZ60AMLH Real Image4 MC9S08DZ60AMLH Real Image5
MC9S08DZ60AMLH Real Image MC9S08DZ60AMLH Real Image2 MC9S08DZ60AMLH Real Image3 MC9S08DZ60AMLH Real Image4 MC9S08DZ60AMLH Real Image5
Same model may have multiple batches, images only for reference.

MC9S08DZ60AMLH

Part No MC9S08DZ60AMLH
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 60KB FLASH 64LQFP / S08 S08 Microcontroller IC 8-Bit 40MHz 60KB (60K x 8) FLASH 64-LQFP (10x10)
Datasheet
MC9S08DZ60AMLH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded>Microcontrollers
Manufacturer Freescale Semiconductor
Packaging Bulk
Core Processor S08
Core Size 8-Bit
Speed 40MHz
Connectivity CANbus, I2C, LINbus, SCI, SPI
Peripherals LVD, POR, PWM, WDT
Number of I/O 53
Program Memory Size 60KB (60K x 8)
Program Memory Type FLASH
EEPROM Size 2K x 8
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2.7V ~ 5.5V
Data Converters A/D 24x12b
Oscillator Type External
Temperature Range - Operating -40°C ~ 125°C
Mounting Surface Mount
Case / Package 64-LQFP
Supplier Device Package 64-LQFP (10x10)
Base Product Number MC9S08
HTSUS 0000.00.0000
Other Part Number NXPFREMC9S08DZ60AMLH,2156-MC9S08DZ60AMLH
Standard Package 1
Win Source Part Number 1318736-MC9S08DZ60AMLH
Ultra Librarian 3D Model Ultra Librarian MC9S08DZ60AMLH CAD Model

Description

The MC9S08DZ60AMLH is an 8-bit microcontroller from Freescale Semiconductor.

  • Core Processor: S08
  • Speed: 40MHz
  • Package: 64-LQFP
  • Voltage Supply: 2.7V to 5.5V
  • Program Memory Size: 60KB (60K x 8)
  • Program Memory Type: FLASH
  • Number of I/O: 53
  • Connectivity: CANbus, I2C, LINbus, SCI, SPI
  • Peripherals: LVD, POR, PWM, WDT
  • Oscillator Type: External
  • Operating Temperature: -40°C to 125°C
  • RAM Size: 4K x 8
  • EEPROM Size: 2K x 8
