The MC9S08QG8CD is an 8-bit microcontroller unit (MCU) from Freescale Semiconductor (now NXP). It is part of the S08 family, designed for low-end applications where cost-effectiveness and low power consumption are critical. This MCU provides a good mix of features for simple embedded control and monitoring tasks.

Applications

• Consumer Electronics: Simple remote controls, entry-level toys, and basic household appliances.
• Industrial Control: Basic sensor interfaces, simple motor control applications, and low-end automation.
• Automotive: Low-cost automotive applications like simple lighting controls or basic sensor monitoring.
• Medical Devices: Low-power portable medical devices with limited processing requirements.

Features

• S08 Central Processing Unit (CPU): Efficient 8-bit processing core.
• 8KB Flash Memory: On-chip non-volatile memory for storing program code and data.
• 512 Bytes RAM: Random access memory for temporary data storage and program execution.
• Analog-to-Digital Converter (ADC): Enables conversion of analog sensor signals into digital values.
• Serial Communication Interface (SCI): Provides UART communication capabilities for serial data transfer.
• Timer/Pulse Width Modulator (PWM): Used for generating PWM signals for motor control and other applications.
• Internal Clock Source: Integrated oscillator eliminates the need for external clock components.
• Low-Voltage Detect (LVD): Protects the system from data corruption during low-voltage conditions.

Benefits

• Cost-Optimized: Designed for price-sensitive applications.
• Low Power: Ideal for battery-powered devices and energy-efficient systems.
• Small Footprint: Available in compact packages, saving board space.
• Easy Development: Supported by a comprehensive development environment and tools.
• Reliable Performance: Provides robust and reliable operation in various environments.

Additional Details

The MC9S08QG8CD operates on a supply voltage range typically between 2.7V and 5.5V. It is often available in small outline packages such as SOIC and QFN. Programming is usually done via a Background Debug Mode (BDM) interface. The device includes a watchdog timer for system monitoring and recovery from potential lockup conditions. Its integrated oscillator reduces the external component count and simplifies the design process.
