MC9S12XET256MAA Real Image MC9S12XET256MAA real image2825
Same model may have multiple batches, images only for reference.
MC9S12XET256MAA Real Image MC9S12XET256MAA real image2825
MC9S12XET256MAA Real Image MC9S12XET256MAA real image2825
Same model may have multiple batches, images only for reference.

MC9S12XET256MAA

Part No MC9S12XET256MAA
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 16BIT 256KB FLASH 80QFP
Datasheet
MC9S12XET256MAA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor HCS12X
Part Core Size 16-Bit
Speed(Frequency) 50MHz
Number of I/O 59
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
EEPROM Size 4K x 8
Data RAM Size 16K x 8
Supply Voltage - Operating 1.72 V to 5.5 V
Data Converters A/D 12x12b
Oscillator Type External
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 80-QFP (14x14)
Win Source Part Number 086276-MC9S12XET256MAA
Family Name MC9S12XET256
Introduction Date October 28, 2008
ECCN 3A991.a.2
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian MC9S12XET256MAA CAD Model

Description

The NXP MC9S12XET256MAA is a high-performance microcontroller designed for industrial use.

  • Flash Memory: 256KB
  • Data RAM Size: 16K x 8
  • Part Core Size: 16-bit
  • Speed: 50MHz
  • Input/Output Pins: 59
  • Oscillator Type: External
  • Voltage Range: 1.72V to 5.5V
  • Temperature Range: -40°C to 125°C
  • Applications: Industrial
  • Popularity: High
  • Supply and Demand Status: Limited
