MPX5700DP Freescale Semiconductor - NXP MPX5700DP Real Image
Same model may have multiple batches, images only for reference.
MPX5700DP Freescale Semiconductor - NXP MPX5700DP Real Image
MPX5700DP Freescale Semiconductor - NXP MPX5700DP Real Image
Same model may have multiple batches, images only for reference.

MPX5700DP

Part No MPX5700DP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR DIFF PRESS 101.5 PSI MAX / Board Mount Pressure Sensor 0.2V to 4.7V 0kPa to 700kPa Differential Automotive 6-Pin Case 867C-05 Tray
Datasheet
MPX5700DP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Differential
Operating Pressure 101.53 PSI (700 kPa)
Output Type Analog Voltage
Output 0.2 V to 4.7 V
Accuracy ±2.5%
Supply Voltage - Operating 4.75 V to 5.25 V
Port Size Male - 0.19" (4.93mm) Tube, Dual
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 406.11 PSI (2800 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 085879-MPX5700DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MPX5700D
Introduction Date December 16, 1994
ECCN EAR99
Country of Origin Republic of Korea, United States of America
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MPX5700DP CAD Model

Description

The NXP MPX5700DP is a differential pressure sensor that operates between -40°C to 125°C temperature range.

  • Port Style: male 0.19" (4.93mm) tube, dual barbed
  • Pressure Range: 101.53 PSI (700 kPa) to 406.11 PSI (2800 kPa)
  • Analog Voltage Output: 0.2 V to 4.7 V with an accuracy of ±2.5%
  • Feature: temperature compensated
  • Operating Voltage: 4.75 V to 5.25 V
  • Commonly Used In: sensors and transducers applications
  • Popularity: high
  • Supply and Demand Status: balanced
  • Estimated EOL Date: 2025
