S9S12H256J1VFVE

Name: S9S12H256J1VFVE
Brand: Freescale Semiconductor - NXP
SKU: 311250
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	S9S12H256J1VFVE
Manufacturer	Freescale Semiconductor - NXP
Catalog	Embedded - Microcontrollers
Description	MCU 16 BIT HCS12 HCS12 CISC 256K
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Embedded - Microcontrollers
Mfr	Freescale Semiconductor - NXP
Package	Bulk
Product Status	Active
Programmable	Not Verified
Core Processor	S12
Core Size	16-Bit
Speed	50MHz
Connectivity	CANbus, I²C, IrDA, LINbus, SCI, SPI, UART/USART
Peripherals	LCD, LVD, POR, PWM, WDT
Program Memory Size	256KB (256K x 8)
Program Memory Type	FLASH
EEPROM Size	4K x 8
RAM Size	6K x 8
Voltage - Supply (Vcc/Vdd)	4.5V ~ 5.5V
Data Converters	A/D 8x8/10b
Oscillator Type	Internal
Temperature Range - Operating	-40°C ~ 105°C (TA)
Mounting Type	Surface Mount
Package / Case	144-LQFP
Supplier Device Package	144-LQFP (20x20)
Base Product Number	S9S12
Standard Package	15 pcs
MSL Level	3 (168 Hours)
REACH Status	Vendor Undefined
HTSUS	0000.00.0000
Win Source Part Number	311250-S9S12H256J1VFVE
Ultra Librarian 3D Model	Ultra Librarian S9S12H256J1VFVE CAD Model

Alternative Products

Description

The S9S12H256J1VFVE is a 16-bit microcontroller from Freescale Semiconductor - NXP.

Core Processor: S12
Speed: 50MHz
Package Type: 144-LQFP
Temperature Range: -40°C to 105°C
Program Memory Size: 256KB (256K x 8)
Program Memory Type: FLASH
EEPROM Size: 4K x 8
RAM Size: 6K x 8
Connectivity Options: CANbus, I²C, IrDA, LINbus, SCI, SPI, UART/USART
Peripherals: LCD, LVD, POR, PWM, WDT
Voltage Supply: 4.5V to 5.5V
Internal Oscillator Type: Internal
