SSFD6035 Silikron Semiconductor Co.,LTD.
Same model may have multiple batches, images only for reference.

SSFD6035

Part No SSFD6035
Manufacturer GOOD-ARK Electronics
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET, P-CH, SINGLE, -26A, -60V
Datasheet
SSFD6035 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr GOOD-ARK Electronics
Package Tape & Reel
Product Status Active
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V
Current - Continuous Drain (Id) @ 25°C 26A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 40mOhm @ 20A, 10V
Vgs(th) (Max) @ Id 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 48 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 3060 pF @ 30 V
Power Dissipation (Max) 60W (Ta)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Supplier Device Package TO-252 (DPAK)
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0080
Win Source Part Number 676614-SSFD6035
Ultra Librarian 3D Model Ultra Librarian SSFD6035 CAD Model

Description

The 676614-SSFD6035 is a P-channel MOSFET with a drain to source voltage rating of 60V and is manufactured by GOOD-ARK Electronics.

  • Continuous Drain Current @ 25°C: 26A
  • Maximum On-Resistance @ 20A, 10V: 40mOhm
  • Package: TO-252-3 (DPak)
  • Standard Package: 2,500 pcs
  • Gate Charge @ 10V: 48 nC
  • Input Capacitance @ 30V: 3060 pF
  • Temperature Range: -55°C to 175°C
  • Applications: applications that require high power and low on-resistance
