TG110-S055N2LF Halo Electronics Inc
Same model may have multiple batches, images only for reference.

TG110-S055N2LF

Part No TG110-S055N2LF
Manufacturer Halo Electronics Inc
Catalog Misc Products
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Halo Electronics Inc
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 840198-TG110-S055N2LF
Package Tube
Product Status Active
Transformer Type LAN 10/100 Base-TX
Turns Ratio - Primary 1CT:1CT Transmitter, 1CT:1CT Receiver
Mounting Type Surface Mount
Size / Dimension 0.500" L x 0.280" W (12.70mm x 7.11mm)
Height - Seated (Max) 0.200" (5.08mm)
Operating Temperature 0°C ~ 70°C
Grade -
Ultra Librarian 3D Model Ultra Librarian TG110-S055N2LF CAD Model

Description

The TG110-S055N2LF from Halo Electronics is a surface mount transformer that is designed for use in a wide range of applications, including LAN, WAN, and xDSL.

  • Turns ratio: 1:1
  • Maximum operating frequency: 100 MHz
  • Package: SMD
  • RoHS directive: meets the requirements
